2 Way Synchronizer (6A)
Model: LK-S122
- Detect the current of each motor in real time, in case one of the motors in the group run abnormally, another will stop to protect the window
- Synchronize 2 linear actuators or 2 chain openers
- Can be controlled by LK-CP6 /FP3 controllers
- Delay time is settable from 0 to 7 seconds
- Protection current can be set from 0.7A to 6.0A
- It’s a current detector cannot synchronize actuators running in real time
Ordering Code | Input Voltage | Output Voltage | Max Current | Synchronized Sets | Working Temp | Dimension |
LK-S122 | 24VDC | 24VDC | 6A*2 | 2 | -20 ~ +65℃ | 120*78*40mm |
Features:
- Synchronize linear actuators or chain actuators to protect the windows not to be damaged
- Easy to install and use.Can be controlled by a variety of controllers or fire control boxes
- One synchronizer can only connect to two actuators
- Made by low-power and high-speed CMOS technology
- Strong anti-interference ability
- Current signal processor, not consume electricity by itself
- Max current of each way is 6A
